Back Side Gearbox Assembly
Product Details:
X
Product Description
Back Side Gearbox Assembly
Clients can avail from us an extensive array of Gearbox Assembly (Back Side). Designed and manufactured from high grade metals and cutting edge technology as per the industry norms, this sheet metal cable tray assures longer life. The cable tray product is corrosion resistance, having accurate dimensions, light weight, perfect finish and durability. To meet the varied needs of clients, we offer this product in different shapes and sizes at most affordable prices.
| Sr. No | Part No. | Description | |
| Extra Long Model | Jumbo Model | ||
| 1 | 2 | 2 | Gear Box |
| 2 | EL 107 | 107 | Weight lever assembly with M.S Rod |
| 3 | EL 106 | 106 | Weight-Gear Side |
| 4 | 108 | 108 | Swing lever-Gear side |
| 5 | 112 | 112 | Weight lever pin-Gear side |
| 6 | 111 | 111 | Hardened & Ground M.S Brush for weight lever pin-Gear Side |
| 7 | 110 | 110 | Hardened & Ground M.S Brush for Swing lever-Gear side |
| 8 | 113 | 113 | Sheet metal cover for swing lever |
| 9 | 32 | 32 | Swing lever cover |
| 10 | 33 | 33 | Oil seal for swing lever cover-55-80-6 |
| 11 | 34 | 34 | Ball bearing for swing lever-6011 |
| 12 | 35 | 35 | Distance piece for swing lever |
| 13 | 109 | 109 | Hardened & Ground swing lever clutch-Gear side |
| 14 | 91 | 91 | Key for clutch-Gear side |
| 15 | 50 | 50 | C.S.K screw-3/16x1/2 Long |
| 16 | 19 | 19 | Hex. nut-5/8 |
| 17 | 20 | 20 | Hex. head bolt-5/8"x4 long |
| 18 | 28 | 28 | Grease nipple-1/8 straight |
| 19 | 26 | 26 | Hex. nut-3/4 |
| 20 | 30 | 30 | Hex. head bolt-5/8x2-1/2 long |
