Cotton Gin Machine Parts
Product Details:
X
Product Description
HUb Assembly
We offer a premium quality Hub Assembly, which is fabricated using quality, approved raw materials in compliance with the industry norms. It is highly appreciated for its optimum performance, corrosion resistance, sturdy construction and compact design. The entire gamut of Hub Assembly is available in different specifications and can be custom designed on specific demands of clients. We assure our clients that product is severely monitored on various parameters and is available at rock-bottom price.
| Sr. No | Part No. | Description | |
| Extra Long Model | Jumbo Model | ||
| 1 | 96 | 96 | C.I HUB |
| 2 | 83 | 83 | Roller Bearing for HUB- NU309 |
| 3 | 95 | 95 | Inside bush for Eccentric shaft (Big) |
| 4 | 94 | 94 | Inside bush for Eccentric shaft(Small) |
| 5 | 82 | 82 | Ball bearing for Hub-6309 |
| 6 | 33 | 33 | Oil seal 55-80-6 |
| 7 | 93 | 93 | Cover for Hub |
| 8 | 92 | 92 | Steel outer ring for Eccentric shaft |
| 9 | 6 | 6 | Hex. head bolt-3/8x1-1/4 long |
| 10 | 106 | 106 | Main pulley-V-belt drive |
| 11 | 66 | 66 | End washer for V-belt pulley |
| 12 | 67 | 67 | Hex. head bolt-5/8"x1-1/2" long |
| 13 | 97 | 97 | Eccentric shaft |
| 14 | 89 | 89 | Eccentric shaft key (main pulley side) |
| 15 | 90 | 90 | Eccentric shaft key (pinion side) |
| 16 | 98 | 98 | Ball bearing housing for connecting rod |
| 17 | 84 | 84 | Ball bearing for conn. rod housing-22211/1211 |
| 18 | 72 | 72 | Circlip for connecting rod housing |
| 19 | 99 | 99 | Steel connecting rod |
| 20 | 53 | 53 | Hex. head bolt-3/8'x2 long |
| 21 | 46 | 46 | Split washer-3/8 |
| 22 | 69 | 69 | Hex. head bolt-5/16x1-1/4 long |
| 23 | 70 | 70 | Split washer-3/8 |
| 24 | 120 | 102 | Hardened and ground wrist pin bush |
| 25 | 100 | 100 | Hardened and ground wrist pin |
| 26 | 28 | 28 | Grease nipple-1/8 straight |
| 27 | 103 | 103 | Eccentric washer |
| 28 | EL 78 | 78 | Hardened and ground steel pinion (22T/16T) |
| 29 | 104 | 104 | Pinion washer |
| 30 | 105 | 105 | Nut for eccentric shaft (left hand thread) |
| 31 | 68 | 68 | Grease nipple-1/4 straight |
| 32 | 71 | 71 | Taper dowel pin for hub |
| 33 | 64 | 64 | Hex. head bolt-1/2x1-1/2 long |
