Front Side Gearbox Assembly
Product Details:
Product Description
Front Side Gearbox Assembly
Our firm is engaged in offering an extensive assortment of Gearbox Assembly (Front Side), which is highly in demand amongst various industries. This assembly is manufactured by our professionals in compliance with the industry norms. The range of Gearbox Assembly (Front Side) is available in various specifications and can be customized as per the precise needs of the clients. This is appreciated for its high performance, compact design, low maintenance, corrosion resistance and durability.
| Sr. No | Part No. | Description | |
| Extra Long Model | Jumbo Model | ||
| 1 | 2 | 2 | Gear Box |
| 2 | 3 | 3 | Gear Box Front cover |
| 3 | 4 | 4 | Gear Box Top cover |
| 4 | 96 | 96 | Hub Assembly |
| 5 | EL 74 | 74 | Steel gear wheel (99T RH/84T RH) |
| 6 | EL 73 | 73 | Steel gear wheel (99T RH/84T RH) |
| 7 | EL 75 | 75 | Steel gear wheel (86T RH/75T RH) |
| 8 | EL 77 | 77 | Steel gear wheel with out boss (46T LH/39T LH) |
| 9 | EL 76 | 76 | Steel gear wheel with boss (46T RH/39T RH) |
| 10 | 79 | 79 | Gear Pin (Long) |
| 11 | 80 | 80 | Gear Pin (Short) |
| 12 | 81 | 81 | Ball bearing for steel gear-6007 |
| 13 | 87 | 87 | Distance piece for long gear pin |
| 14 | 85 | 85 | Dutty washer for gear pin |
| 15 | 56 | 56 | Hex. Socket head cap screw-3/8â€ÂÂx1 Long |
| 16 | 6 | 6 | Hex. Head bolt-3/8x1-1/4-Long |
| 17 | 26 | 26 | Hex. Nut-3/4 |
| 18 | 63 | 63 | Thick washer for gear |
| 19 | 71 | 71 | Dowel pin for Hub and gear box |
| 20 | 89 | 89 | Key for pulley |
| 21 | 64 | 64 | Hex. Head bolt-1/2x1-1/2 Long |
| 22 | 65 | 65 | Hex. Head bolt-1/2x 2 Long |
| 23 | 88 | 88 | Key for steel gear with boss |
| 24 | 86 | 86 | Distance piece for short gear pin |
| 25 | 55 | 55 | Hex. Socket head cap screw-3/8x1-1/2 Long |
| 26 | 54 | 54 | Hex. Head bolt-5/16x1/2 long |
| 27 | 135 | 135 | Sheet metal inspection hole cover |
| 28 | 52 | 52 | Split washer-1/2" |
| 29 | 58 | 58 | Plain washer-1/2" |
